3-Years Warranty
4th Generation Core i3/i5
Rugged
ITS 485 Titan Series
Touchscreen POS - Ultimate Workhorse
Description :
iCE ITS-485 Titan Series comes with a borderless 15” True-Flat Resistive or PCAP display with Intel Bay Trail or Haswell Processor and a rugged housing made of aluminum die-casting. It offers customizable rich I/Os and supports a variety of peripheral modules such as MSR, Fingerprint, and iButton. ITS-485 is built to withstand any harsh environment and handle the most demanding application. It is configured in a manner for easy upgradability and serviceability.
Product Features:
- 4th Generation Intel core i3 & i5 Processor
- Borderless 15” True-Flat Touch Display
- Easy Swap HDD
- 3-Track MSR Available
- iButton and Fingerprint Available
- 2nd Display and Customer Display available
- Elegant Die-Casting Housing
- Easy Serviceability and Upgradability
- Fanless and Silent
|
Mother Board |
Type Processor |
D36* Intel Bay Trail CPU Celeron J1900 2.4GHz |
D66* Intel Core i3-4330, 3.5GHz, Cache 4MB Intel Core i5-4570S, 2.90GHz, Cache 6MB |
|
Chipset |
CPU Integrated |
Q87 (AMT technology) |
|
|
System Memory |
1 x DDR3L 1066/1333MHz SDRAM up to 8GB |
1 x DDR3 1333/1600MHz SDRAM up to 8GB |
|
|
Graphic Engine |
Intel Gen7@>300MHz |
Intel HD Graphic Dx11.1 |
|
|
LCD Touch Panel |
LCD Size |
15" TFT LCD |
15" TFT LCD |
|
Brightness |
250nits |
250nits |
|
|
Resolution |
1024 x 768 |
1024 x 768 |
|
|
Touch Screen |
True Flat Resistive or PCAP Touch |
PCAP True Flat Touch |
|
|
Tilt Adjustment |
0" ` 90" |
0" ` 90" |
|
|
Storage Device |
Hard drive |
1 x 2.5" SATA HDD |
1 x 2.5" SATA HDD |
|
Flash Memory |
1 x SATA SSD card (Option) |
1 x SATA SSD card (Option) |
|
|
Expansion |
Mini PCI-E Socket |
1 |
1 |
|
External I/O Ports |
USB |
1*USB3.0/2.0, 4*USB2.0 |
1*USB3.0/2.0, 4*USB2.0 |
|
Serial Port |
3*RJ45 (COM1/2 5V,COM3 12V) |
3*RJ45 (COM1/2 5V,COM3 12V) |
|
|
LAN |
1*RJ45 |
1*RJ45 |
|
|
Cash Drawer |
1*RJ11 |
1*RJ11 |
|
|
Parallel Port |
1 (Option) |
1 (Option) |
|
|
VGA |
1*DB15 |
1*DB15 |
|
|
Audio Line-out |
1 (Option) |
1 (Option) |
|
|
DC Jack |
1 |
1 |
|
|
Indicator |
LED Indicator |
1 |
1 |
|
Power |
Power Adapter |
65W / 19V |
125W / 19V |
|
Communication |
Wireless LAN |
802.11 b/g/n WLAN card & antenna (Option) |
802.11 b/g/n WLAN card & antenna (Option) |
|
Peripheral (Option) |
MSR |
3-Track MSR (USB) |
3-Track MSR (USB) |
|
iButton |
iButton (USB) |
iButton (USB) |
|
|
Fingerprint |
Digital Persona Module (USB) |
Digital Persona Module (USB) |
|
|
2nd Display |
8.4"/ 15" without touch |
8.4"/ 15" without touch |
|
|
Customer Display |
VFD display 2*20 characters (COM) |
VFD display 2*20 characters (COM) |
|
|
Certificate |
EMC & Safety |
FCC Class A, CE Mark, LVD |
FCC Class A, CE Mark, LVD |
|
Dimension(W*D*H) |
361*248*337 mm (14.2"*9.8"*13.3") |
361*248*337 mm (14.2"*9.8"*13.3") |
|
|
Weight |
8 kg (17.6 lbs) |
8 kg (17.6 lbs) |
|
|
OS Supported |
Windows 7,POSReady 7,Windows Embedded 8.1 Industry,Windows 10 IoT Enterprise (D66 only supports 64bit), Linux |
||
