ITS-150 Titan Series


Touchscreen POS - Affordable & Retail Trusted

Description :

Today POS systems are indispensable in every industrial sector for higher level of efficiency and accuracy in its operations. TITAN Series ITS-150 Touch Panel provides excellent Quad Core performance, providing functionality to the hospitality & retail industry ensuring a productive work environment. ITS-150 features Intel Celeron J1900 CPU with True Flat 5-Wire Resistive Touch Panel along with IP54 Certi­fied Spill Proof and Anti-dust protection.

Product Features:

  • Intel Celeron J1900 CPU
  • 5-Wire / True Flat 5-Wire Resistive Touch Panel
  • HDD Easy Maintenance
  • IP54 Certi¬≠ficated Spill Proof and Anti-dust
  • Reliable and consistent quality to Point-of-Sales requirement
  • Flexible architectures for peripherals, Detachable Stand / Support VESA mounting

2 Years Warranty

Low Cost & High performance

Easy Maintenance

Spill Proof & Anti-Dust

Main Board

Processor

Intel Celeron J1900 2.0GHz, Cache 2MB

Chipset

CPU Integrated

System Memory

1 x DDR3L SO-DIMM, up to 8GB

Display & Touch

LCD Size

15" TFT LCD(LED backlight)

Brightness

250nits

Resolution

1024 x 768

Touch Technology

True Flat 5-Wire Resistive (ITS-150FT) 5 -Wire Resistive (ITS-150)

Storage

HDD/SSD

1 x 2.5" SATA HDD or SSD

I/O & Expansion

DC Input

1 x Mini Din 4P (DC 19V only)

Cash Drawer

1 x RJ-11 (12V or 24V(default))

LAN port

1 x Gigabit Ethernet by RJ-45

USB port

4 x USB 2.0 , 1 x USB 3.0

COM port

3 x RS-232 (RJ48 connector), COM1/2/3 Pin10 w/RI/5V/12V Selectable by BIOS (default is RI)

VGA Port

1X DB-15 VGA port, Power enabled by BIOS setting (default disable)

Bus Expansion

1 x Mini PCI-E Slot

Power Switch

1 x power on/off switch button

Speaker

HD Audio, 2W Speaker x 2

OS Support



Windows 8, Windows 7, POSReady 7

Power Adapter



External adapter, DC Model: 65 Watts, Voltage: +19VDC 3.42 Amax

Compliance

Certifications

CE, FCC, LVD, RoHS

VESA Mount



75 mm x 75 mm VESA

Material



Main Unit: Plastics Housing

Color



Main Unit: Black

Dimensions



365 x 200 x 339

Weight



5.8kgs

Environment



0 o C ~ 40 o C, 20% ~ 85% RH, non-condensing

Condition



Storage Condition

-20 o C ~ 55 o C, 20% ~ 80% RH, non-condensing

Optional

VFD

VFD: 2 x 20 attached

Accessories

MSR

Front, 3 tracks USB Type

iButton

USB Type

SCR

Combo MSR / Smart Card Reader, USB Type

Warranty



2 years warranty
